Indoor Cat5e FTP full copper cable lan cable communication cable
Features:
1. Full copper conductor
2. Color-coded PE insulation
3. Rip cord (Optional)
4. Lead free PVC or LSOH jacket
5. Flammability grade:CMX,CM,CMG,CMR
6. TIA/EIA 568B IEC/ISO 11801
7. Rated temperature: 60C,75C |
| Cat5e FTP Lan Cable |
Cat5e FTP Lan Cable
1.Specification
* Specification: 4P
* Rated Temperature: -40¡ãC ¡« + 75¡ãC
* Unshielded twisted pairs
* Conductor: 23AWG or 24AWG Str&ing or Solid Bare copper
* Insulation: HDPE
* Filler: PE Cross or FM-PE Thin slice
* Drain Wire: 23AWG or 24AWG Str&ing or Solid Tinned copper
* Outer Shielded: AL-Mylar 100 %( min) coverage
* Unrip rope: optional
* Jacked: PVC or LSNH
* Impedance: 100¡À15% ¦¸ at 1 ~250MHz
* Reference St&ard: YD/T1019-2001¡¢ANSI/TIA/EIA-568B¡¢ISO/IEC11801
* Print Legend: CM or CMR
2.Scope Application
Mainly used in the Building Correspondence Synthesis Wiring System the Work Area
Correspondence Leading-out Terminal & between the Connection Distribution Frame
Wiring, As Well As the Housing Synthesis Wiring System¡¯s User Correspondence
Leading-out Terminal Arrives at Place of Exile between Coils¡¯wiring
Product Structures
|
|
Cat5e UTP Network Cables
